How to confirm that the product is a 14×14 cm beam with a confusing URL?
The Shopify title is "Beams 14×14 cm," but the handle contains text for 14×16 and "copy." The variants only differ in length, not in cross-section. Therefore, before ordering, LATIVA must physically confirm the 14×14 cm size by SKU, label, or measurement. Do not rely solely on the URL or the general photo when preparing a construction list.
What lengths and codes are available for the beam titled 14×14 cm?
The variants are 3 m LT-4523, 4 m LT-4522, 5 m made to order LT-4521, and 6 m made to order LT-4520. Due to the URL discrepancy, the order must include the full title, length, SKU, and explicitly confirmed 14×14 cm cross-section. For custom lengths, delivery time, transport, and acceptance must be agreed upon before payment.
What is the nominal volume of a 14×14 cm beam?
The nominal cross-sectional area is 0.0196 m². The volume is 0.0588 m³ for 3 m, 0.0784 m³ for 4 m, 0.0980 m³ for 5 m, and 0.1176 m³ for 6 m. Use these values only after confirming that the physical product is indeed 14×14 cm. Actual dimensions, moisture content, and processing can affect the actual volume.
How do the nominal cross-sections 14×14 and 14×16 cm compare?
The nominal areas are 196 cm² and 224 cm², so 14×16 has about 14.3% larger cross-section. This compares material volume, not load-bearing capacity. For 14×16, orientation also matters, while 14×14 is square. The two active products have different SKUs and confusing handles, so the physical cross-section must be confirmed before substitution or cutting.
What wood qualities are needed for a load-bearing 14×14 cm beam?
For calculation, at least the wood species, strength class, moisture content, grading, and allowable defects are needed. It must also be known whether the beam is dried, planed, or treated. Shopify does not contain this data, so the 14×14 cm title is not a sufficient structural specification. Request a traceable batch document and coordinate it with the project.
How to select metal connectors for a square 14×14 cm beam?
Plates, shoes, bolts, and screws are selected based on calculated forces, actual cross-section, edge distances, and wood class. Do not use a connector just because it nominally fits 140 mm. Due to the incorrect handle, first physically confirm the size. Then the project specifies the number and diameter of fasteners, corrosion protection, and bearing method.
